在GWT的文檔里說,大致上CSS的命名規則是這樣的"[project]-[widget],比如gwt-Button,你可以在CSS里定義如下:
.gwt-Button{font-size:150%;}
但是這樣的說明是不充分的,所以這里有必要把他真正的樣式表來列一下,以供查看。
AbsolutePanel
用一個DIV來實現,默認的設置了overflow:hidden。這個DIV里邊的內容可以用一個x,y坐標來確定位置。
<div style="overflow: hidden;"></div>
Botton
就是一個正常的HTML的Button.默認的樣式名字是gwt-Button.
<button class="gwt-Button"/>
CellPanel
用一個table來實現,沒有默認的樣式,可以設置border,cell-spacing屬性。
<table></table>
CheckBox
就是正常的Html的CheckBox,默認的樣式名字為gwt-CheckBox,會自動生成一個不重復的id,checkN(N是一個整數),可以使用checked,defaultChecked,disabled等屬性。默認樣式是空的。
<checkbox class="gwt-CheckBox">
DeckPanel
用一個DIV來實現,包含了一系列的子對象。每一個對象可以用單獨的display屬性來設置是否顯示。這個有點像Swing里面的CardLayout的方式有點像,添加了一系列的組件,但是只能顯示一個。
<div style="width: 100%; height: 100%"></div>
DialogBox
缺省的樣式有gwt-DialogBox,Caption兩個都是相關。用一個DIV來實現,標題Caption也是一個DIV。
<div class="gwt-DialogBox">
<table cell-spacin="0" cell-padding="0">
<tbody>
<tr><td><div class="Caption">Caption</div></td></tr>
<tr><td>Content</td></tr>
</tbody>
</table>
</div>
DockPanel
用一個Table來實現,cell-spacin,cell-padding都默認為0,為了實現DockPanel里邊的tr,td比較麻煩一些。
<table cell-spacing="0" cell-padding="0">
<tbody></tbody>
</table>
FlexTable
只是一個簡單的Table,沒什么特別的東西。
<table>
<tbody></tbody>
</table>
FlowPanel
用一個DIV來實現,設定里display屬性為inline。
<div style="display:inline;">content</div>
FocusPanel
只是一個DIV,重要的是它聲明了focusevents,keyevents,onclick和mouseevents,對對于那些沒有聲明的這些事件"子組件"很有用處。
<div>content<div>
FocusWidget
可以是任何組件,只是它可以幫助捕獲Focusevents,keyevents。
Frame
是一個IFrame,他的默認的樣式是gwt-Frame
<iframe></iframe>
Grid
就是一個Table
<table><tbody></tbody></table>
HTML
一個DIV,默認的樣式是gwt-HTML,可以設定屬性white-space為normal,nowrap。
HTMLPanel
就是一個DIV,可以容納HTML或是其他組件,不適用gwt-HTML樣式。最有用的屬性就是createUniqueId,可以設定一個id,HTMLPanel_N。和前面的CheckBox的checkN,相比,這里用大寫字母和下劃線。看起來多少有點怪異。
<div>content</div>
HTMLTable
沒有疑問,這是用一個Table實現的,重要的是,它是Grid,FlexTable的父類。提供了設定每行或是每一個單元格的樣式設定的方法。表格中沒有thead。假如要設定表頭的話,可能通過設定第一行的樣式來區別。
<table><tbody></tbody></table>
table.getRowFormtter(0).setStyleName("style");
HorizontalPanel
水平排列的面板,用一個只有一行的表格實現。
<table cell-spacing="0" cell-padding="0">
<tbody>
<tr>
<td style="display: static; vertical-align: top;" align="left">Item 1</td>
<td style="display: static; vertical-align: top;" align="left">Item 2</td>
</tr>
</tbody>
</table>
HyperLink
一個有定義了錨點的DIV,默認的樣式名:gwt-HyperLink
<div></div>
沒有問題,肯定是IMG.gwt-Image樣式沒有實現。
<img src="..."/>
Label
一個DIV,默認的樣式是gwt-Label。Label不能解析HTML內容,假如你想要的話,可以用HTML來代替,兩者都提供鼠標事件。Label會自動換行,但是你也可以通過setWordWrap來修改。
<div class="gwt-Label">content</div>
ListBox
就是用Select和Option來實現。gwt-ListBox樣式沒有被實現。可以設定selected,size,multples等屬性。
MenuBar
用一個包含表格的DIV實現。一個水平的菜單,只有一行,用單元格來設置菜單項,一個垂直的菜單,用行來區分菜單項。gwt-MenuBar只是設定外層的DIV的樣式。
<div class="gwt-MenuBar">
<table>
<tbody>
<tr>
<td class="gwt-MenuItem">text or html</td>
<td class="gwt-MenuItem">text or html</td>
</tr>
<!--一個垂直菜單的例子
<tr><td class="gwt-MenuItem">text or html</td></tr>
<tr><td class="gwt-MenuItem">text or html</td></tr>
-->
</tbody>
</table>
</div>
MenuItem
一個菜單項就是在菜單條中的一個單元格。它的默認屬性是gwt-MenuItem.選中的時候有一個附加的屬性,gwt-MenuItem-selected.在菜單項默認的樣式class="gwt-MenuItem",在選中的時候就改變成class="gwt-MenuItem gwt-MenuItem-selected".
PasswordTextBox
用Password實現,使用gwt-PasswordTextBox樣式。
PopupPanel
只是一個DIV.
RadioButton
用一個INPUT實現,使用gwt-RadioButton樣式。
RootPanel
一個RootPanel可以附加到任何的組件上,但是以前屬于這個組件的所有的內容都會被清除。假如你仔細想想,你會發現除了初始化之外,這個組件還有很多用處。
ScrollPanel
一個Div設定了overflow屬性為scroll 或auto.
<div style="overflow: auto;">
content
</div>
SimplePanel
就是一個Div.
StackPanel
用一個表格來實現,每一個組用兩行來保存,第一行放了標簽,第二行放了內容。默認的這個表格使用gwt-StackPanel樣式,標簽行用了gwt-StackPanelItem和gwt-StackPanelItem-selected.當一個標簽被選中的時候,它的樣式就由原來的gwt-StackPanelItem替換成為gwt-StackPanelItem-seleted.
<table class="gwt-StackPanel" cell-spacing="0" cell-padding="0">
<tbody>
<tr>
<td class="gwt-StackPanelItem" height="1px">text/html</td>
</tr>
<tr>
<td height="100%" valign="top">
content -- a widget
</td>
</tr>
</tbody>
</table>
TabBar
TabBar使用一個HorizontalPanel來實現,所以它也是一個Table,表格的樣式是gwt-TabBar。對于第一個標簽,通常是一個空的,它的樣式是gwt-TabBarFirst,就是為了裝飾,最后也會加上一個空的標簽,指定樣式為gwt-TabBarRest。當一個標簽被選中的時候,gwt-TabBarItem-selected的樣式會附加到樣式中,這點和MenuItem是一樣的。
<table class="gwt-TabBar" cell-spacing="0" cell-padding="0">
<tbody>
<tr>
<td class="gwt-TabBarFirst" style="height: 100%;"><div class="gwt-HTML" style="height: 100%;">&nbsp;</div></td>
<td>Tab #1</td>
<td>Tab #2</td>
<td class="gwt-TabBarRest" style="width: 100%;"><div class="gwt-HTML" style="height: 100%;">&nbsp;</div></td>
</tr>
</tbody>
</table>
TabPanel
用一個VerticalPanel來實現,包含了一個TabBar和一個DeckPanel,這樣就嵌套幾層表格,樣式gwt-TabPanel用到最外層表格。gwt-TabBar用到TabBar,gwt-TabPanelBottom用到DeckPanel的DIV上了。需要注意的是TabBar獲取了width:100%樣式,這樣你就知道TabBar中的gwt-TabBarRest樣式的必要了。
<table class="gwt-TabPanel" cell-spacing="0" cell-padding="0">
<tbody>
<tr>
<td>
<table class="gwt-TabBar" style="width: 100%;" cell-spacing="0" cell-padding="0">
<tbody>
<tr>
<td class="gwt-TabBarFirst" style="height: 100%;"><div class="gwt-HTML" style="height: 100%;">&nbsp;</div></td>
<td class="gwt-TabBarRest" style="width: 100%;"><div class="gwt-HTML" style="height: 100%;">&nbsp;</div></td>
</tr>
</tbody>
</table>
</td>
</tr>
<tr>
<td>
<div class="gwt-TabPanelBottom">
</div>
</td>
</tr>
</tbody>
</table>
TextArea
就是一個TextArea,默認的樣式為gwt-TextArea.
TextBox
<input type="text" class="gwt-TextBox" />
Tree
就是一個包含了多個TreeItem的Div,默認樣式gwt-Tree,設定overflow:auto.
<div class="gwt-Tree" style="overflow: auto;">
<div style="position: relative; margin-left: 16;" (handle)>
<table>
<tr>
<td></td>
<td></td>
</tr>
</table>
</div>
</div>
TreeItem
用一個包含了一個表格的DIV來實現。默認的樣式gwt-TreeItem和gwt-TreeItem-selected,來修飾里面的內容。但選中的時候gwt-TreeItem-selected會替換gwt-TreeItem。這個StackPanel是一樣的。
<div style="position: relative; margin-left: 16; white-space: nowrap" (handle)>
<table style="white-space: nowrap;">
<tr>
<td style="vertical-align: middle;"><img src="tree_white.gif" /></td>
<td style="vertical-align: middle;">content</td>
</tr>
</table>
children
</div>
VerticalPanel
用一個表格來實現,所有的東西按行來排列。
<table cell-spacing="0" cell-padding="0">
<tbody>
<tr><td style="display: static; vertical-align: top;" align="left">Item 1</td></tr>
<tr><td style="display: static; vertical-align: top;" align="left">Item 2</td></tr>
</tbody>
</table>
參考:
http://blogs.nubgames.com/code/?p=13
